實驗臺技術參數的英文版本 1.Product table: 12.7mm solid psychological board test bench, thicken the edge to prevent liquid leakage. Acid and alkali resistant, chemical solvent, non-toxic, long service life. 2.Product cabinet: 1.0mm high qua...
實驗臺技術參數的英文版本
1.Product table: 12.7mm solid psychological board test bench, thicken the edge to prevent liquid leakage. Acid and alkali resistant, chemical solvent, non-toxic, long service life.
2.Product cabinet: 1.0mm high quality cold rolled steel plate is cut, punched, bent and welded in CNC machining center. After pickling and phosphating, epoxy resin powder is sprayed and solidified at high temperature. High adhesion and beautiful appearance.
3.Door panel and drawer panel: 1.0mm high quality cold-rolled steel plate (double layer), without welding connection, detachable, with shock pad. In CNC machining center processing molding, cutting, positioning, punching, bending, welding, pickling, phosphating, spraying epoxy powder, high temperature curing, high adhesion.
4.Product drawer: 1.0mm thick high-quality cold-rolled steel plate is cut, punched, bent and welded in the CNC machining center, the surface is pickled and Phosphated, and then coated with epoxy resin powder, high-temperature curing.
5.Product handle: 1.0 mm thick high quality cold-rolled sheet is used for numerical control processing to form the whole handle.
6.Product hinge: equipped with DTC special hinge, no noise when switching, more than 50000 times.
7. Product slide: use DTC three-stage 14 inch guide rail.
8.Process Description: spray all epoxy resin powder on the steel plate, with smooth appearance and no solder joint. All water, electricity and gas pipelines shall be installed in a safe, applicable and concealed manner. There is no backplane for all test beds, and the backplane under all cabinets can be disassembled flexibly for maintenance and safety inspection.
以上就是江蘇吳上科技小編給大家?guī)淼年P于“實驗臺技術參數的英文版本”的全部內容,希望可以幫助大家,如果您有采購實驗臺通風柜的需求,可以和我們吳上聯系廠家直銷,現貨供應!價格合理。
